An Overview | Trinity 22B Bulb

The Trinity 22B Bulb topper is a progression from our well-proven Trinity 22B potato topper. The bulb-specific topper shares many elements of the potato version but also possesses many of its own unique features.

The front half of the hood is up-rated to thicker steel to cope with harsh stony conditions. The separate rear section of the hood has been extended, and special deflectors have been developed to enable the chopped haulm to be controlled and directed into the tractor wheelings far more effectively. By delivering 100% of the chopped haulm to the tractor wheelings, a faster, more efficient harvest is achieved. A sliding headstock and a heavy-duty front curtain are available as options.

Standard Specification:

• Reduced running costs– competitively priced wearing parts and quick-change flails for reduced downtime.
• Heavy duty stub axles, wheel bearings, and easy-rolling oversize wheels.
• Greatest range of cutting height due to superior depth wheels.
• Rotors feature heavy-duty 55mm taper lock bearings.
• Greater variation in flail length to allow better flailing in row bottoms and also flat blades across the row top for maximum suction.
• Replaceable stainless steel inner liner for hood protection is unique to the Trinity range of toppers.
• Shear plates to assist in fine chopping of haulm with the choice of single row or full bed width deflectors.
• Inspection hatches.
• Adjustable row and bed widths range from 75cm to 100cm.
• Rear diffuser for better control of chopped haulm.
